Full automatic PET HDPE PP plastic bottle mouth neck Cutting
Trimming machine
Introduction
Holding bottle device, and moved device, and deflashing device
three in one whole. The machine has features of good quality, high
safety performance,compact structure,simple operation and
maintenance,small volume,light weight,low noise and so on.You can
change few accessories to cut size diameter of plastic drum and
incision is smooth carrot-free.
The merit is: holding bottle device, and moved device, and
deflashing device three in one whole,not only can deflash edge on
the blow molding line and blow bottle ,but also can guarantee
deflashing device and holding bottle device to move synchronously
so that eliminate the movement error.Ensure cutting quality,and the
whole structure is simple with high cutting efficiency.
U TECH MACHINE Automation Trimmer bottle-head machine advantage:
1. Import control systems, the PLC of Mitsubishi, high quality, at
present, the saled machine without any bad records;
2. Controlling through the man-machine system, quicky and facility,
industry display, easy to adjust the dates, starting automation by
one key;
3. The induction system uesd the import digitization sensor,
accurately, high precision, good quality, excellent stability;
4. Suit for the kinds of some bottles that the bottle’s diameter is
in small distance, and trimmer another kind only by changing a
clamp and ajusting the guard rail;
5. At present only one station, but it will be more stations in the
near future;
6. The machine made by metal plate, and through high temperature
spraying, firm frame and stability, used by long time without
distortion;
7. All the pnecmatic element is the Taiwan Airtac, producing the
more using value for our customers.
Technical parameters
Description | Bottle neck cutting machine |
Specifications | PLC--Japan MITSUBISHI Display--XINJIE OP320-A Vacuum generator--SMC photoelectric sensor:Autonics laser-probe emission spectrometer: Autonics or RBX Motor--TAIWAN ZhongDa frequency converter:Japan MITSUBISHI Button--France SCHNEIDER electric relay—France SCHNEIDER Cylinder--TAIWAN Airtac Air valves: Taiwan Airtac |
Conveyor | 3 meters |
Size | 2000×1050×1800(mm)-According to Sample Design |
Weight | 450kg |
Power | 380V,50Hz,0.75KW |
Air pressure | 5kgf/cm2 |
Count for capacity | Have |
Speed control | Support (1500-1800 units per hour) |
Deflashing remove | have |
Suitable bottle trimmer | According to sample and design neck size |
Deliver Time | 35 days |
Payment Terms | 40% T/T down payment, 60% T/T paid off after samples approval
before delivery |
Price Lalid Time | 35 days |
Warranty Period | 2 year |
Remarks | If special product,please inform us in advance |
| U TECH MACHINE CO.,LTD |
Delivery
Packaging Type:
We usually use wooden case as packaging type.It’s suitable for
long-distance transport.Other packaging type such as sheet iron
case and so on could be offered as customer's demmand.
Transport:
By sea.
Company Information
Zhangjiagang U Tech Machine Co., Ltd. is a manufacturer of filling
machine and packing with well-equipped testing facilities and
strong technical force. With a wide range, good quality, reasonable
prices and stylish designs, our products are extensively used in
beverage and other packing equipment.
Our products include: liquid filling machines (water, fruit
juice/tea, carbonated drink, oil, alcohol, plant protein drink,
etc.), barreled filling line (3-5 gallon) water treatment machines,
labeling & packing machines, semi-automatic /full automatic PET
bottle blowing machines, and injection molding machines, extrusion
blow molding machines (PP/PE/PVC/PETG/PC...) and accessories for
automation: leak tester machines, bottle bag packing machines,
conveyor belts.
Our service
Before order service
We will according to your requirement make details quotation for
you.
We can send you some our machine running video similar to your
product.
If you come to china,we can pick you up from airport or station
near our city.
After order service
We will start to make machine,and take some picture by 10 days of
our production process.
Our engineer can design the layout according to your requirement.
We will supply commission service if customer need.
After-sales service
We will testing machine ,and take some video and picture to you if
u not come to china inspect machine.
After testing machine we will packing machine ,and delievery
container on time.
We can send our engineer to you country help you install and
testing machine.we can training you technical until they can
running machine independent.
Our company will give you all machine with 2 years guarantee.in 2
years you can get all spare parts free from us.we can send you by
express.
